SolidWorks | AutoCAD | PDM
Steel Shop Drawings · Permit Packages · Custom Fab Details
Building or remodeling? I can guide you from first sketch to final inspection.
Kelso, WA · Serving Cowlitz County, the Pacific Northwest and beyond
Email TonySee ServicesRecent work
Stair towerOrange juice plant, Tipton, CA
Fire-damaged home rebuildResidential permit set and SolidWorks model
Stadium grandstandLongview Memorial Stadium upgrade
Training center mezzanineSteel framing and shop drawings
60-ton valve removal rigCustom fabrication details
Mezzanine deckSteel framing and pan deck
Tank support steelPlatforms, stairs and bracing
Steel deck with spiral stairCustom residential steel
Covered deck additionResidential permit drawings
Garage truss repairResidential permit set, Kalama, WA
From model to installMezzanine steel on site
From a single part drawing to a full fabrication package or a residential permit set, every drawing is done by me, start to finish.
We provide precise and detailed mechanical drafting services. From 2D technical drawings to 3D models, we create accurate drawings for machine parts, assemblies, and mechanical systems. Our designs meet industry standards, ensuring efficiency in manufacturing and production.
Learn more →We specialize in accurate and detailed structural drafting for Manufacturers, Production Plants, and Heavy Steel Construction Projects. Using advanced CAD software, we create precise shop and reinforcement drawings that meet industry standards, ensuring accuracy and efficiency.
Learn more →We provide professional home permit drawings to ensure your project meets local codes. Our detailed site plans, floor plans, and elevation drawings streamline the approval process for renovations, additions, and new constructions. Let us help you get permits quickly and hassle-free.
Learn more →Planning a new house, addition or remodel? Get someone in your corner who speaks both drafting and construction, from first sketch to final inspection.
Learn more →TK Drafting Solutions offers different types of SolidWorks and AutoCAD services, from simple drawing conversions to advanced detailing and fabrication level drawing packages. You get the drawing package that best fits your technical requirements while producing the right set of project deliverables.
Small shops and big plants alike. If it needs to be drawn right, I can help.
I grew up in Camp Grisdale, the last existing logging camp in Washington State, about 50 miles east of Aberdeen in the Olympic National Forest, and graduated from Wishkah High School just outside Aberdeen.
After high school I served four years in the US Navy aboard the USS Enterprise. Straight out of the military I joined the Sheet Metal Union, completed my apprenticeship through the JATC of Western Washington, and worked on large-scale commercial projects around the state.
From there I went to college and earned two AAS degrees, the primary one in design graphics with a mechanical emphasis. I went on to design custom light fixtures for hotels, casinos and malls, then spent years as a CAD consultant in California supporting project managers at food processing plants, wineries, manufacturers and more.
Today I'm back home in Washington, running TK Drafting Solutions out of Kelso as a Certified SOLIDWORKS Professional.
Who issues your permit, what drawings they expect, how long it takes, and why a little homework up front saves weeks later. Plain advice for homeowners in Kelso and Cowlitz County.
Read more →For years my file system was me, a bunch of folders, and a lot of "Rev_C_final_FINAL2." Here is why a one-man shop needs a file vault, and what it means for your drawings.
Read more →Send me your sketch, model, markups or idea and a little about what you need. I'll get back to you with questions and a quote.
